ATX Motherboard Products
| Products | Model Name | Motherboard Chipset | CPU | I/O | Expansion |
|
QY-MB-B75-ATX
|
Intel B75 |
Support Intel 2nd/3rd Generation Core / Pentium / Celeron Desktop CPU, LGA1155 Support MAX CPU TDP: 65W |
2*LAN ports 11*USB ports 6*COM ports |
1*PCIE 16X Slot 1*PCIE 4X Slot 1*PCIE 1X Slot 4*PCI Slot 1*Mini-PCIE Slot (WIFI+4G, with 1*Full-Size SIM Card Slot |
|
QY-MB-H81-ATX
|
Intel H81 | Support Intel Pentium / Celeron / 4th Generation Core i3/i5/i7 CPU,LGA 1150 |
2*LAN ports 10*USB ports 6*COM ports |
1*PCIE 16X Slot 1*PCIE 4X Slot 1*PCIE 1X Slot 4*PCI Slot 1*Mini-PCIE Slot (WIFI+4G, with 1*Full-Size SIM Card Slot |
|
QY-MB-H110-ATX
|
Intel H110 |
Support Intel Pentium / Celeron / 6-7th Generation Core i3 / i5 / i7 CPU, LGA 1151 Support MAX CPU TDP: 65W |
2*LAN ports 9*USB ports 6*COM ports |
1*PCIE 16X Slot 1*PCIE 4X Slot 1*PCIE 1X Slot 4*PCI Slot 1*Mini-PCIE Slot (WIFI+4G, with 1*Full-Size SIM Card Slot) |
|
QY-MB-H310C-ATX
|
Intel® H310C |
Support Intel® 6/7/8/9th Generation CoreTM/Pentium®/Celeron® Desktop Processors LGA1151, Support MAX CPU TDP: 65W |
2*LAN ports 4*USB 3.0 ports 5*USB 2.0 ports 6*COM ports |
1*PCIE 16X Slot 1*PCIE 4X Slot 1*PCIE 1X Slot 4*PCI Slot 2*Mini-PCIE Slot |
|
QY-MB-Q270-ATX
|
Intel® Q270 |
Support Intel® 6/7/8/9th Generation Core / Pentium/ Celeron Desktop CPU, LGA1151 Support MAX CPU TDP: Octa-Core 95W |
2*LAN ports 13*USB ports 6*COM ports |
1 * PCI-E 16x Slot (PCI-E 3.0, PCIE 8X Signal, PCIE 16X Optional) 1 * PCI-E 16x Slot (PCI-E 3.0, PCIE 8X Signal) 3 * PCI-E 4x Slot (PCI-E 3.0, PCIE 4X Signal) 2 * PCI Slot 1 * PCI CLK 66MHz/33MHz Select Jumper 1 * Mini PCI-E Slot (PCIE+USB2.0, Support WIFI+4G/3G, with1 * SIM Card Slot) |
|
QY-MB-H470-ATX
|
Intel® H470 |
Intel® 10th Generation Core i3/5/7/9, Pentium® , Celeron® Processors, Comet Lake-S Support MAX CPU TDP: Hexa-Core 65W, Deca-Core 35W |
2*LAN ports 13*USB ports 6*COM ports |
1 * PCI-E 16x Slot 1 * M.2 Key-E Slot (PCIE+USB2.0, Support WIFI+ BlueTooth, 2230) 1 * PCIE4X Slot (PCIE 2X, PCIE4X_2) 4 * PCI Slot 1 * PCIE4X Slot (PCIE 4X, PCIE4X_3) |
|
QY-MB-Q470-ATX
|
Intel Q470 |
Support Intel 10th/11th Generation Core / Pentium / Celeron Desktop CPU, LGA1200 Support MAX CPU TDP: Deca-Core 125W |
2*LAN ports 13*USB ports 6*COM ports |
1 * PCI-E 16x Slot (PCIe 16X GEN3) [5] 1 * PCI-E 16x Slot (PCIe 8X GEN3, no resources by default) [5] 3 * PCI-E 4x Slot (PCIe 4X GEN3) 2 * PCI Slot 1 * Mini PCI-E Slot (WIFI+4G/3G, with1 * Full-Size SIM Card Slot) 1 * PCI CLK 66MHz Enable/Disable Select Jumper 1 * PCI-E Signal Select Jumper |
|
QY-MB-H610-ATX
|
Intel H610
|
Support Intel® 12/ 13/ 14th Generation Core / Pentium/ Celeron Desktop CPU
LGA1700 Support MAX CPU TDP: 8+4 Core 65 W |
2*LAN ports 10*USB ports 6*COM ports |
1 * PCI-E 16x Slot (PCIe 16X, GEN4)
2 * PCI-E 4x Slot (PCIe 2X, GEN3)
1 * PCI-E 4x Slot (PCIe 2X, GEN3, PCIE-4X-SLOT3)
3 * PCI Slot
1 * PCI CLK 66MHz Enable/Disable Select Jumper
|
|
QY-MB-Q670-ATX
|
Intel Q670 |
Support Intel® 12/13th Generation Core / Pentium/ Celeron Desktop CPU, LGA1700 Support MAX CPU TDP: 8+8 Core 125W |
2*LAN ports 13*USB ports 6*COM ports |
1 * PCI-E 16x Slot (PCIe 8X, GEN4) 1 * PCI-E 16x Slot (PCIe 8X, GEN4) 3 * PCI-E 4x Slot (PCIe 4X, GEN4) 1 * PCI-E 4x Slot (PCIe 4X, GEN3) 1 * PCI Slot 1 * M.2 Key-E Slot (PCIE+USB2.0+ CNVi, support WI FI +Bluetooth Module, 2230) 1 * PCI CLK 66MHz Enable/Disable Select Jumper |
