Industrial Panel PC P8000 Series
Support Win 7/ 10 / 11 and Linux system
4:3 size: 7 / 8 / 10.4 / 12.1 / 15 / 17 / 19
16:9 size: 10.1 / 13.3 / 15.6 / 17.3 / 18.5 / 21.5 / 23.8 / 27 / 32
Power input: DC 9-36V
The P8000 series of new generation industrial tablet computers have a modular design, capacitive touch/resistive touch options, and a molded shell. It presents an effective fusion of high reliability and industrial aesthetics, interpreting the sophisticated quality of industrial computers in industrial design. and technological fashion elements, it is the best choice for high-end smart equipment. This series of products has high anti-interference design and strong scalability, which can meet the requirements for use in harsh industrial environments. It has good dustproof, heat dissipation, vibration resistance, and EMC performance. It has high system reliability and strong environmental applicability. It is a Products for industrial automation industry, medical informatization, and industrial field control applications.
The QY-8000 series is an industrial tablet computer with a modular design. The connection between the panel and the host adopts a reliable modular design and wireless relay link. Through flexible matching, it can realize the selection of multi-specification all-in-one computers and single hosts without changing the original site. Designed to be quickly upgraded and maintained.
P5000 Series Products
| Products | Model Name | Display | CPU | I/O | Expansion |
|
QY-P5104
|
10.4 inch Capacitive/Resisitive Touchscreen 4:3 Screen Resolution: 1024*768 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5121
|
12.1 inch Capacitive/Resisitive Touchscreen 4:3 Screen Resolution: 1024*768 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5133
|
13.3 inch Capacitive/Resisitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5150
|
15.0 inch Capacitive/Resisitive Touchscreen 4:3 Screen Resolution: 1024*768 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 2/4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5156
|
15.6 inch Capacitive/Resisitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5170
|
17.0 inch Capacitive/Resisitive Touchscreen 4:3 Screen Resolution: 1280*1024 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COM optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5173
|
17.3 inch Capacitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
360-270.jpg)
|
QY-P5185
|
18.5 inch Capacitive Touchscreen 16:9 Screen Resolution: 1366*768 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5190
|
19.0 inch Capacitive/Resisitive Touchscreen 4:3 Screen Resolution: 1280*1024 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COM optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5215
|
21.5 inch Capacitive/Resisitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5238
|
23.8 inch Capacitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5270
|
27.0 inch Capacitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
|
QY-P5320
|
32.0 inch Capacitive Touchscreen 16:9 Screen Resolution: 1920*1080 Brightness: 350 nits, support 500 / 800 / 1000 nits |
Intel Celeron Core 3/4/6/7/8/10/11/12th-i3 / i5 / i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: Standard 2*COM(DB9 type), 6*COMS optional Display: 1*HDMI:+1*VGA Audio: 1*SPK+1*MIC Power Input: DC12V, DC9-36V optional |
2*Mini PCIE slots for 4G and WIFI module |
